IKON GROOVE Front Rim 406x32 36H

389,99 € Tax incl.

Recommended retail price : 389,99 € TTC

Quantity

Colors

Reference:

Availability:

View Combination List

Buy in local shop

DESCRIPTION

IKON Exclusive Double Walled, T800 & T700 UD Carbon fiber combo weave. This combination of T700 & T800 offer the strongest and lightest 406 Pro rim currently offered in BMX. Optimized Internal Geometry used to maximiz strength and deliver a lighter rim.
Tested and approved by the pilots of the CHASE team.

FEATURES :
• Toray T800 & T700 UD Carbon Rim
• Dimensions: 406x30mm (20"x1.50"/1.75")
• Front profile without braking surface
• Tubeless Ready
• Width: 30mm
• Height: 20/26mm
• ERD: 383.2/371.2mm
• Drilling: 36 holes
• Valve: Presta F/V
• Weight: 300g

NOT COMPATIBLE FOR V-BRAKE
Maximum recommended pressure: 110Psi / 7.58 bar
Recommended spoke tension: ≤115KGF

Spokes information (3 cross)

FRONT HUB MODELS	NON DRIVE		DRIVE
FRONT HUB MODELS	Outside	Inside	Inside	Outside
Box One Stealth Pro Oversized 20mm Front Hub 36H	180mm	178mm	180mm	178mm
Excess EXE Pro Front Hub 20mm or 10mm 36H	180mm	178mm	180mm	178mm
Onyx BMX Solid or Helix Front Hub 20mm or 10mm 36H	182mm	180mm	182mm	180mm
Onyx BMX XL 100 Grooved or Helix Front Hub 36H	182mm	180mm	182mm	180mm

REAR HUB MODELS	NON DRIVE		DRIVE
REAR HUB MODELS	Outside	Inside	Inside	Outside
Box One Stealth Pro Oversized 20mm Disc Rear Hub 36H	182mm	172mm	178mm	176mm
Excess EXE Center Lock Pro P3x5 R120 Rear Hub 36H	182mm	172mm	180mm	178mm
Excess EXE ISO Pro P3x5 R120 Rear Hub 36H	182mm	172mm	180mm	178mm
Onyx BMX ULTRA ISO HG-110/10mm Bolt-On or 110/15mm Thru-bolt Rear Hub 36H	182mm	172mm	180mm	178mm
Onyx BMX ULTRA SSD ISO OX-110/10mm Bolt-on or 110/15mm Thru-bolt or 110/20mm Thru-bolt Rear Hub 36H	182mm	172mm	178mm	178mm

Note: Spoke lengths are provided for reference only.

IKON carbon rims are some of the lightest carbon rims on the market, but strength has not been sacrificed. Made from a T800 & T700 UD Carbon fiber combo weave manufactured by Toray, the leader in the field, more resistant than other 3K weaves, all for a featherweight 300g per rim! A comparable alloy rim of the same size / width weighs 390g, which saves you up to 180g for a pair of rims!

Rims without a braking surface can be used as a front rim but also a rear rim when using a disc brake.

Tubeless Ready System : IKON rims feature a Bead Lock System, needed for the rim to be Tubeless Ready. With the installation of additional items needed you can get the rim ready for tubeless set up, along with the usage of a tubeless specific tire. With a tubeless set up, you can lighten up your wheels, saveing rotational weight, as well as have a sealant inside your tubeless ready tire to help automatically repair small punctures. Additional items needed to convert to a Tubeless system include Special Valve, Sealant Rim Tape, and Liquid sealer.
